Empire Comfort Systems HMFA-1 Instructions D'installation
Masquer les pouces Voir aussi pour HMFA-1:

Publicité

Liens rapides

INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch;
do not use any phone in your building.
Leave the building immediately.
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
42724-0-1120
All manuals and user guides at all-guides.com
INSTALLATION INSTRUCTIONS
HEAT MANAGEMENT SYSTEMS KIT
Empire Comfort Systems Inc. • Belleville, IL
HMFA - 1 FORCED AIR
HEAT MANAGEMENT
SYSTEMS KIT
FOR USE WITH
DIRECT - VENT
FIREPLACE
MODELS:
DVLL(36,48,60,72)BP
DVL(36,46)BP
WARNING
If not installed, operated and maintained
in accordance with the manufacturer's
instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
We suggest that our gas
hearth products be
installed and serviced by
professionals who are
certified in the U.S. by the
National Fireplace Institute
(NFI) as NFI Gas Specialist.
GAS-FIRED
UL FILE NO.
MH30033
DVCT(36,40,50)CBP
DVCT40CSP
®
Page 1
