14. Ohmic values of the sensors according to the
temperature
Outside unit discharge sensor / condenser sensor
° C
0
5
10
15
20
25
30
35
° C
-30
-25
-20
-15
-10
-5
0
5
Outside unit air sensor / middle tank sensor / tank top sensor
° C
-10
-5
0
5
10
15
122 122
K ohm
169
130
101
79
63
50
40
32
Outside unit evaporator sensor
K ohm
96
69
50
37
28
21
16
12
K ohm
62
47
35
27
21
16
Installation
° C K ohm
40 26
45 22
50 18
55 15
60 12
65 10
70 8.7
75 7.4
° C K ohm
10 9.6
15 7.6
20 6
25 4.8
30 3.8
35 3.1
40 2.5
45 2.1
° C K ohm
20 13
25 10
30 8
35 6.4
40 5.2
45 4.2
Use
° C K ohm
80 6.3
85 5.4
90 4.6
95 4
100 3.4
105 3
110 2.6
115 2.3
120 2
° C K ohm
50 1.7
55 1.4
60 1.2
65 1
70 0.8
75 0.7
80 0.6
° C K ohm
50 3.5
55 2.8
60 2.4
65 2
70 1.6
75 1.4
80 1.2
