4.6 - Standard installation

ATTENTION !
For anything not indicated, please refer to paragraph 4.1
ATTENTION !
DO NOT REMOVE THE REAR COVER!
Fix the bracket to the cross beam (FIG. 25), then connect the steel
rail using one of the two long screws supplied (FIG. 38) and to
follow the instructions of TAB. 1C and TAB. 2.

4.7 - Manual opening of the door

In the event of a power failure and if the optional buffer battery is not available, to unlock the automation system:
PHASE DESCRIPTION
1 Pull the cord in order to bring the release lever to its vertical position (FIG. 29)
2 Lift or lower the door manually
3 To reset the automation system, move the cord so as to allow the release lever to fit fully back into the pulling slider (FIG. 35)
4 Lift or lower the door manually until it engages with the rail

4.8 - Fixing the LED rail opening limit stop

Unlock the slider, manually lift the door until it is in its maximum
possible indicated opening position H - 10 cm (FIG. 43).

4.9 - Fixing the steel rail opening limit stop

Unlock the slider, manually lift the door until it is in its maximum
possible indicated opening position H - 10 cm (FIG. 43).

4.10 - Electrical wiring

ATTENTION !
Before connecting, check that the control unit is not powered
Follow the connection instructions (FIG. 49)
ELECTRICAL WIRING
COM FLASH, LED output common
FLASH Flashing output 24Vdc (not regulated), maximum 3W
LED Courtesy light output 24Vdc (not regulated), maximum 20W
PH-POW Photocell power positive output 24Vdc (not regulated), maximum 100mA
NEG Photocell power negative output
PH Photocells (closing) NC contact between PH and COM
EDGE/EDGE Sensitive edge input, NC contact, 8k2 resistive or 8k2 double resistive (parallel)
STEP BY STEP NO contact control between SBS and COM
SBS
Open/Stop/Close/Stop control or control based on software selection
NO contact STOP between STOP and COM. The contact can be activated at any time and will immediately lock the
STOP
automation system, disabling any function including automatic closing
COM SBS, STOP input common
L1 RED LED indicating programming of control panel parameters
MENU Key for programming control panel parameters
RADIO Key for programming integrated radio parameters
Raise the rail until parallel to the ground, measure the dimension
A and then cut the two ceiling brackets as shown: dimension A + 3
cm (FIG. 39). Insert the quick coupling plate, then connect it to the
ceiling brackets (FIG. 40, 41).
Fix the brackets to the ceiling using suitable screws and anchors
(not supplied).
Follow the instructions in section 4.1 from FIG. 28 to FIG. 34, by
inserting the arm in the slit of the slider previously cut open with a
utility knife (FIG. 42).
Mark the end position of the slider with a pencil (FIG. 44), then drill
a hole and fix with the screw (FIG. 45).
Firmly fasten the limit stops (FIG. 46).
