4 - PRODUCT INSTALLATION

4.1 - Simply assembly with LED rail and installation on Spring shaft
Before starting assembly operations, make sure to have all the
necessary tools available (FIG. 2).
Place the rail on a flat surface, protecting it from any scratches.
Remove the plastic cap and take out the LED adjustment board.
Cause the transmission pulley to slide until the screw protrudes
more from the end of the rail, unscrew the nut, insert the tensioning
spring and re-tighten the nut until belt tension is ensured (FIG. 5, 6).
Bring the head close to the rail and place it on a flat surface,
protecting the bottom cover from potential scratches. Remove
the rear cover by applying pressure to the two points indicated
(FIG. 7).
Remove the white cover (FIG. 8), use a utility knife to cut the two
rectangles on the white cover and remove them (FIG.9).
Open the indicated door by cutting the plastic material with a utility
knife and lifting it gently (FIG. 10), then insert the LED adjustment
board (contained in the rail package) with the cables already
inserted (FIG. 3, 11). Gently close back the cover. Place the cables
in the special slots, inserting the cable without connector into the
indicated hole (FIG. 11).
Insert the metal adapter inside the hole on the rail with the help of
a rubber mallet (FIG. 12) then insert the rail on the head, taking
care to match the adapter grooving to the motor pin's (FIG. 13) and
connect the connector (FIG. 14).
ATTENTION !
Check that the cables are inside their provided seats before
positioning and tightening the upper plate (FIG. 15) to avoid
crushing them. Tighten the 4 cross-head screws.
Open the side door, remove the cable and connect the wires to the
control unit (FIG. 16). Close back the side door.
Place the motor on the spring holder shaft (FIG. 17), lift the rail until
parallel to the ground, measure the dimension A (distance between
the rail and ceiling) and then cut the threaded bar to a measure
corresponding to A - 5 cm (FIG. 18). The threaded bar and the
fixing components are included with the LED rail.
Assemble the components of the threaded bar (FIG. 19). Fix the
threaded bar to the ceiling using suitable screws or anchors (not
supplied) (FIG. 20). Assemble and insert the lower part of the
bracket into the rail causing it to slide in the slots (FIG. 21) then
insert the plastic cap in the rail.
Connect the threaded bar to the hexagonal nut at the top of the
rail, turning the bar, until it goes in by about 1 cm, in order to have

4.2 - 3-part rail assembly

Assemble the rail (FIG. 4) then pull the belt (FIG. 6)

4.3 - Single rail assembly

Pull the belt (FIG. 6)

4.4 - Connection of the motor casing to the steel rails

Follow the instructions in section 4.1 (FIG. 12, 13, 15)

4.5 - Installation with motor casing on cross beam

ATTENTION !
For anything not indicated, please refer to paragraph 4.1
28
a perfectly horizontal rail. Then tighten the nuts in the indicated
sequence (FIG. 22).
Insert the long screws and turn them by hand, to allow the nuts to
fit back inside their seats (FIG. 23). Allow the screws to protrude
by a few millimetres, so that the bracket can be inserted in the
provided slot. Use the slot to position the bracket on the cross
beam and mark the positions of the holes (FIG. 24).
Move the motor to the side and fix the bracket using suitable
screws and anchors (not supplied) (FIG. 25).
Reposition the motor on the bracket.
ATTENTION !
Now turn the long side screws only slightly (FIG. 37). Do not
tighten hard so as not to damage the nut seats.
Tighten the lock nuts (FIG. 26) hard, while holding the screws in
place with a hexagonal wrench.
ATTENTION !
Do not turn the screws to avoid breaking the nut seats, turn
exclusively the lock nuts until tight.
Fix the lower jaws (FIG. 27).
Fix the bracket to the upper part of the door, in a central position (FIG.
28) and exactly in the middle of the C-shaped bracket (FIG. 25).
Measure the indicated dimensions (TAB. 1A) and put together the
connecting arm with the indicated parts (TAB. 2).
Release the slider by operating the release cord (FIG. 29).
Pull the slider clip, insert the curved arm and its pin inside it (FIG.
30, 31, 32, 33) and tighten the 2 countersunk-head screws to close
the clip. Also tighten the 2 countersunk head screws symmetrically
at the opposite end of the slider.
Connect the arm to the door (FIG. 34), then reset the slider by
moving the release cord to allow the lever to retract and lock it,
moving the door manually until it engages (FIG. 35).
Remove the transparent stickers provided to protect the rail and
LED diffuser profiles (FIG 36).
After completing the programming (next paragraphs), fix the safety
screw (FIG. 51) and place the white cover back (FIG. 52).
Follow the instructions in section 4.1 from FIG. 24; please be
careful not to connect the bracket to the slot, but to the single hole
(FIG. 37) and to follow the instructions of TAB. 1B and TAB. 2.
Then continue following the instructions in section 4.1
