R8MTS MACHINE OVERVIEW
1. CUTTING HANDLE
2. ROTARY TABLE
3. RETRACTABLE LOWER BLADE GUARD
4. MITRE ANGLE LOCKING HANDLE
5. MITRE ANGLE SCALE
6. CUTTING HEAD RELEASE LEVER
7. CUTTING HEAD LOCK DOWN PIN
8. PUSH STICK STORAGE
9. TABLE SAW ON/OFF SWITCH
10. MITRE SAW ON/OFF TRIGGER
4 5 2
11
1
10
7
