Illustration 4
5.4.2 Turning tool on and off
A control handle can be mounted on right of the engine to switch the tool (in this case: Axial sweeping unit) on and off. There
are 3 different positions.
1.
To activate the drive, push the handle forwards (see Illustration 1). The brush will now start to rotate in a forward
direction.
Illustration 1
2.
Leave the handle in the middle to activate the neutral position which also switches the brush off. (see Illustration 2)
Illustration 2
3.
The machine is also equipped with a position for driving backward. Pull the handle backwards.
Illustration 3
The tool drive is equipped with an overload protection. If the force requested from the tool is too high, it will stop as long asthis
force is requested. If the tool jams, move the machine back. If the tool continues to be jammed, turn off the machine and have it
checked by a mechanic. Never check the tool while the machine is running.
5.4.3 Angle adjustment of the Axial sweeping unit
The Axial sweeping unit can be placed in an angled position in relation to the direction of movement. To place the Axial
sweeping unit in an angled position or release the brush from its angled position, lift the pin and turn the equipment. (see
Illustration 1)
27
Farm-Clean
Illustration 5
Tuchel Maschinenbau GmbH
