4.
When the handle is left in the middle, the machine is in neutral. The machine will not move. (see Illustration 2)
Illustration 2
5.
For backward position, use the rear handle. Pull it against the pushing bar. The machine will now move backward.
(see Illustration 3)
Illustration 3
It is not allowed to install devices to lock the handle that controls the machine's movements in a certain position. The installation
of such device or any other device of the same purport will result in cancellation of the guarantee.
3.4 Stand use
On the side of the case, a stand has been installed. You can pull it out if you want to
support the machine when you want to leave it standing without a tool unit mounted.
Follow the procedure below to pull out the stand:
1.
Unscrew the handle screw by turning it to the left (see Illustration 1). If no tool has been mounted, make sure to keep
a firm grip on the machine. This to avoid damages.
Illustration 1
2.
Now you can pull out the stand. If the stand reaches its desired position, tighten the handle screw by turning it to the
right (see Illustration 2).
Illustration 2
22
Farm-Clean
Tuchel Maschinenbau GmbH
