Liste des pièces
N°
Désignation (ENG)
1
Main frame
2
Front stabilizer
3
Rear stabilizer
4
Seat post
5
Front post
6
Handlebar
7
Flywheel
8
Seat adjustable tube
9
Computer fixing plate
10
Computer
11
Elliptical base
12L
Seat protective cover(Left)
12R
Seat protective cover(Right)
13
Belt
14
Pulley
15
Crank axle
16
Bearing#6004-2RS(C0)
17L
Left crank
17R
Right crank
18
Bolt cover
19
Anti-loosen nut M10*1.25*10T
20
C-clip(D22.5*D18.5*1.2T)
21
Waved
washer(D27*D20.3*0.5T)
22
Flat washer(D26*D21*1.5T)
23L/23R
Pedal set(L&R)
24
Allen bolt M6x1.0x15L
25
Nylon nutM6x1.0x6T
26
Bearing(#6002-2RS)
27
C-clipS-15,1T
28
Flywheel shaft
38
Référence pièce fab.
850A1-3-1000-J4
850A1-3-2100-J2
850A1-3-2112-J2
850A1-3-2200-J3
850A1-3-2000-J2
850A1-3-2400-BB0
850A1-6-3101-02
745S0-3-4000-J4
850A1-6-2402-J1
850A1-6-2501-B2
850A1-6-2173-B0
746S0-6-2282-B1
746S0-6-2283-B1
58004-6-1128-00
58008-6-1042-D0
850A1-3-2903-00
58006-6-1040-01
58007-6-1097-D0
58007-6-1098-D0
81502-6-2779-B0
70501-6-2775-N0
55519-1-2312-DA
55120-5-2705-DA
55120-1-2615-NA
58029-6-1160-B2
50106-5-0012-C0
55206-1-2006-CA
58006-6-1014-00
55515-1-0010-D0
850A1-6-3171-00
Spécification
SI67121O-64
540 (1372) ,pj7
D260*21*2T
#6004-2RS(C0)
M10*1.25*10T
D22.5*D18.5*1.2T
D27*D20.3*0.5T
D26*D21*1.5T
JD-005,9/16"
M6x1.0x15L
M6x1.0x6T
#6002-2RS
S-15,1T,15
D15*135L
IC70 Smart
Nbre
1
1
1
1
1
1
1
1
1
1
4
1
1
1
1
1
2
1
1
2
2
2
1
1
1
4
5
2
2
1
