1.1 ultimateSAM Humidifi cation System
(SA*)
Each UltimateSAM Humidifi cation System consists of the following:
•
humidifi er steam distributor;
•
Components for pressurised steam, such as: actuators, valves, strainers
and steam traps (sold separately);
•
a controlling humidistat and/or sensor (sold separately);
•
a steam control valve & actuator for use with pressurized steam sources
(sold separately);
•
other optional equipment that may be required.
1.2 Distributor dimensions and weights
1.2.1
Dimensions and weights of the SAB* / SAT* and
distributors
" Y "
The system for identifying the humidifi er steam distributor is shown in
Table 1.b. The table also provides the width (Dimension "X") and height
(Dimension "Y"). The front-to-back depth of all distributor is the same,
133mm (5.25"). NOTE: The height dimension assumes that the bottom
pedestals are in the factory-assembled position (see section 1.4 for details
on other pedestal heights).
The weights of the various distributor confi gurations, including the frame,
are shown on Table 1.a. The table shows weights for only the smallest and
largest width and height distributors. A complete weight table for all width
and height codes can be found in the "Technical specifi cations" manual.
Weight in kg (lb)
A
SABA*SI3*0
7.5 ( 17)
SABA*LI3*0
8.0 ( 18)
SABA*HI3*0
8.5 ( 19)
SABR*SI3*0
44.0 ( 97)
SABR*LI3*0
46.0 (101)
SABR*HI3*0
47.5 (105)
SATA*SI3*0
10.0 ( 22)
SATA*LI3*0
10.0 ( 22)
SATA*H3*0
10.5 ( 23)
SATR*SI3*0
55.0 (121)
SATR*LI3*0
56.5 (124)
SATR*H3*0
58.5 (129)
1. INTRODUCTION AND ASSEMBLY
" X "
Fig. 1.a
Height Code
Q
21.0 ( 46)
22.5 ( 50)
25.5 ( 56)
126.0 (277)
139.5 (307)
202.5 (446)
23.0 ( 51)
24.5 ( 54)
28.0 ( 62)
137.0 (301)
150.0 (330)
213.5 (470)
Tab. 1.a
SA x
x
1
2
ID prefi x
‚
Feed type:
B= Bottom feed
T=Top feed
ƒ
Width
Code
A=
B=
C=
D=
E=
F=
G=
H=
I=
J=
K=
L=
M=
N=
O=
P=
Q=
R=
„
Height:
Code
A=
B=
C=
D=
E=
F=
G=
H=
I=
J=
K=
L=
M=
N=
O=
P=
Q=
…
Uprights:
Code
S=
L=
H=
†
Insulation:
I= insulated uprights with nozzles
N= uninsulated uprights without nozzles
‡
Frame:
0= no frame, unassembled
1= no frame, assembled
2= with frame, unassembled
3= with frame, assembled
ˆ
Drain:
U= ¾" Male NPT (only for North America)
0= ¾" Male Gas
‰
---
---
For additional dimensions regarding features on the distributor, like drain
locations, see the "Technical specifi cations" manual. See other sections of
this manual for details on other ultimateSAM items, such as valves and traps.
Note: some models/versions are specifi c for certain markets, and
consequently are not available in some countries. The fl anged
accessories are not available for North America. Contact the CAREL sales
network for availability.
7
"ultimateSAM - user" +03U0070EF - rel. 1.0 - 23.05.2013
ENG
x
x
x
x
x
0
8
9
3
4
5
6
7
Dimension
No. of uprights
152mm
76mm
"X" mm (in)
(6") spacing
(3") spacing
447 (17.75)
2
3
599 (23.75)
3
5
751 (29.75)
4
7
903 (35.75)
5
9
1055 (41.75)
6
11
1207 (47.75)
7
13
1359 (53.75)
8
15
1511 (59.50)
9
17
1663 (65.50)
10
19
1815 (71.50)
11
21
1967 (77.50)
12
23
2119 (83.50)
13
25
2271 (89.50)
14
27
2423 (95.50)
15
29
2575 (101.50)
16
31
2727 (107.50)
17
33
2879 (113.50)
18
35
3031 (119.50)
19
37
Dimension "Y" mm (in)
Botom feed
Top feed
598 ( 23.75)
749 ( 29.50)
750 ( 29.75)
901 ( 35.50)
902 ( 35.75)
1053 ( 41.50)
1054 ( 41.50)
1205 ( 47.50)
1206 ( 47.50)
1357 ( 53.50)
1358 ( 53.50)
1509 ( 59.50)
1510 ( 59.50)
1661 ( 65.50)
1662 ( 65.50)
1813 ( 71.50)
1814 ( 71.50)
1965 ( 77.50)
1966 ( 77.50)
2117 ( 83.50)
2118 ( 83.50)
2269 ( 89.50)
2270 ( 89.50)
2421 ( 95.50)
2422 ( 95.50)
2573 (101.50)
2574 (101.50)
2725 (107.50)
2726 (107.50)
2877 (113.50)
2878 (113.50)
3029 (119.50)
3030 (119.50)
3181 (125.25)
Interasse
OD mm (in)
mm (in)"
152 (6.00)
35 (1.50)
152 (6.00)
45 (1.75)
76 (3.00)
35 (1.50)
Tab. 1.b
