8.6 Retainer ring kit for SAB*
SAKF R x 0 0 0 0
Family prefix
5
Pos.
Meaning
Option
Description
†
Size mm (in)
S
Retainer Ring for uprights O.D. 35
L
Retainer Ring for uprights O.D. 45
Ogni kit SAKFR*0000 include: 3pz anelli di fi ssaggio.
8.7 Gaskets kit
Kit of nozzle O-rings and nozzle gaskets for manifolds with condensate
drain. Kit of gaskets for steam inlet accessories
SAKG x x 0 0 0 0
Family prefix
5
Pos. Meaning
Option
…
Type
U
I
†
Upright size mm (in)
O
S
L
Each SAKGU*0000 kit includes: 2 O-rings; 2 gaskets for drain manifold
Each SAKGI00000 kit includes: 2 gaskets.
8.8 Filter "Y" kit
SAKT x F x x x 0
Family prefix
5
Pos.
Meaning
Option
…
Material:
‡
ˆ
Dimension:
-
‰
Region:
"ultimateSAM - user" +03U0070EF - rel. 1.0 - 23.05.2013
6
7
8
9
10
Tab. 8.e
Fig. 8.h
6
7
8
9
10
Description
U = Uprights Gasket kit
I = Inlet Gasket kit
for SAKGI0000
SAKGU: S = uprights O.D. 35
SAKGU: L = uprights O.D. 45
6
7
8
9
10
Description
F
Iron
S
Stainless steel
15
Flange DN 15
20
Flange DN 20
25
Flange DN 25
32
Flange DN 32
34
Threaded
3/4
pipe
"
40
Flangia DN 40
44
Threaded
pipe 1"
50
Flange DN 50
65
Flange DN 65
84
Threaded
pipe 2"
U
0 = Other
O
U = U.S.
Fig. 8.i
8.9 Condensate drain separator Kit
SAKT x P x x x 0
Family prefix
Pos.
Meaning
…
Material:
‡
ˆ
Dimension:
-
‰
Region:
Tab. 8.f
8.10 F&T Condensate drain Kit
SAKT x D x x x 0
Family prefix
Pos.
Meaning
…
Material:
‡
ˆ
Dimension:
-
‰
Region:
Tab. 8.g
24
5
6
7
8
9
10
Option
Description
F
Iron
S
Stainless steel
15
Flange DN 15
20
Flange DN 20
25
Flange DN 25
32
Flange DN 32
34
Threaded
pipe
3/4
"
40
Flangia DN 40
44
Threaded
pipe 1"
50
Flange DN 50
65
Flange DN 65
84
Threaded
pipe 2"
U
0 = Other
O
U = U.S.
Fig. 8.j
5
6
7
8
9
10
Option
Description
F
Iron
S
Stainless steel
15
Flange DN 15
20
Flange DN 20
25
Flange DN 25
32
Flange DN 32
34
Threaded
3/4
pipe
"
40
Flangia DN 40
44
Threaded
pipe 1"
50
Flange DN 50
65
Flange DN 65
84
Threaded
pipe 2"
U
0 = Other
O
U = U.S.
Fig. 8.k
Tab. 8.h
Tab. 8.i
