Control elements and connections

General

The functions are all arranged in a logical way on the control panel. The various welding
parameters can easily be selected with the press of a button and can just as easily be
-
-
As a result of software updates, you may find that your device has certain functions that
are not described in these Operating Instructions, or vice versa. Certain illustrations may
also differ slightly from the actual controls on your device, but these controls function in
exactly the same way.
Description of the
control panel
Danger from incorrect operation.
This can result in serious injury and damage to property.
▶
▶
Control panel
(1)
(2)
changed using the adjusting dial
shown on the display during welding
WARNING!
Do not use the functions described here until you have read and completely unders-
tood these Operating Instructions.
Do not use the functions described here until you have fully read and understood all
of the Operating Instructions for the system components, in particular the safety
rules.
(6) (4)
(2)
( ) 9 (7)
Adjusting dial
for changing parameters. If the indicator on the adjusting dial is lit up, then the
selected parameter is one that can be altered.
Parameter selection button
for selecting the following parameters
(11)(10) (12)
(5)
(3) (3)
(1)
( ) 8
