Num'axes CANICOM 1000 Guide D'utilisation page 21

❖ « Booster » button
Press the Booster button to stop your dog instantaneously. You can choose the stimulation level you
think to be the best for an immediate effect. As a result, you do not need to press the « + » button.
Those stimulations are transmitted by the two contact points located on the collar for as a long as
the button is pressed but no more than 8 seconds max.
The stimulation level selected thanks to the "Booster" button can be different for each collar.
If you press the « Booster » button for more than 8 seconds, the collar will automatically go into
safety mode for a few seconds before restarting itself normally.
« Booster » button configuration for the dog «1»:
- press the "1" button until the stimulation level flashes on the LCD screen
- press the "+" or "-" button to modify the stimulation level
- press the "1" button to confirm the level selected
Renew the same procedure to program the Booster button for the dog 2.
❖ « + » and « - » : stimulation level control buttons
Use the "+"/"-" buttons for rapid adjustment of the stimulation level of the receiver collar.
18 levels are available.
Level 1: very weak stimulation. Level 18: strong stimulation.
Always start with the lowest level of stimulation.
❖ Retro-lightning of the LCD screen
You can light the LCD screen for approximately 6 seconds by pressing briefly the On/off switch (
(approx. 1/2 second).
Checking/replacing batteries of remote control
Performance (radio range) of the remote control may deteriorate as batteries become weak. Be
prepared to replace batteries.
To check the condition of the batteries, turn on the remote control and look at the battery level indicator
on the LCD screen.
Batteries fully charged.
Weak batteries: prepare to replace them.
Dead batteries: your CANICOM 1000 functions in safety mode and the system locks up.
Batteries must be replaced.
Remove the old batteries and replace them with new ones :
- On the back of the remote control, unscrew the screw and remove the battery cover.
- Remove the old batteries.
- Insert the new batteries (LR06 alkaline) paying attention to follow polarity indicated on the battery
housing. (ref. Diagram 6).
Gb - 21
( (
)
