1. OVERVIEW
1.1 Product Features
 1.3 / 2 Megapixel solution with HDTV 720p / 1080p quality, allowing users to notice minor details more easily
 ONVIF standard supported to simplify system integration
 POE (Power-over-Ethernet) support to eliminate the use of power cables and reduce installation costs
 Remote Surveillance
-- Full compatibility on iPhone & iPad, and Internet Explorer® on Windows® operating system
 IR LEDs built-in for night surveillance
 (For selected model only) External alarm I/O device connection
 (For selected model only) Equipped with a vari-focal lens of f2.8 ~ 12mm, suitable for various monitoring environments.
 (For selected model only) WDR to increase image recognizability in overexposure and dark areas.
 (For selected model only) Zoom lens of f6.0 ~ 60mm with 10x optical zoom, 10x digital zoom and auto focus, suitable for
various monitoring environments.
 (For selected model only) Micro SD card support for video storage.
 (For selected model only) Built-in heater which can operate at temperatures as low as -40℃.
 (For selected model only) Push Video to send event notifications to iOS or Android devices immediately
1.2 Package Content
 Standard Package
 IR Camera
 Optional Accessories
 Screws & wall plugs
 Wrench
 Desiccant
 Installation sticker
1.3 Cable Overview
Note: The connectors available depend on the model you have.
Cable
Power cable
RJ45 network cable
RESET:
GND
Alarm in / Alarm out*
Line in (Blue)* / Line out (Green)*
* For selected models only
 Quick Guide
 CD manual
 Bracket
 Sun shield
Description
Connect to DC12V power supply.
Note: The power adapter is optional.
Connect it to the supplied RJ45 cable extender adapter for cable extension, and prepare
another RJ45 network cable with suitable length for your connection.
With the power connected, press to reset all parameters, including the IP address to
factory default settings.
The camera will reboot after default reset. Please do not disconnect your camera
during the reset process.
Ground wire, used for reset default or external device connection.
For external alarm device connection, please refer to "1.4 External Alarm Connection
(For selected models only)" at page 2.
Support speaker and microphone connection.
