3.3.6 Advanced
Adjust the camera parameters if necessary.
Note: The functions available depend on the model number used.
Item
Fixed Shutter*
Shutter Speed
Exposure Control*
Exposure Value*
Back light*
Mirror
Flip
De-noise*
IR Control
IR Enhanced*
IR Turn On Level*
White Balance
Sharpness
Wide Dynamic
Range*
Digital WDR*
*Selected models only
Description
Shutter Speed is a function that can adjust the duration of the electronic shutter to produce optimum image quality. Select
the shutter speed suitable for your environment.
Select the shutter speed suitable for your environment.
A slower shutter speed in dark conditions will help to produce a brighter image, but will produce fewer frames per second,
which may cause images to get blurry during motion.
When "Auto" is selected, the iris mode is "AES".
When a certain speed is selected, the iris mode is switched to "AI", and the image brightness is available to adjust from "IRIS".
This function is used to synchronize the shutter time to the fluorescent light to suppress image flickering.
Drag the slider to adjust the exposure level from 0 ~ 4.
It is the function to adjust the image to compensate for an area that is overpowered by brightness because of excessive light.
The image will be properly exposed for clearness. Select to activate (ON) or disable (OFF) this function.
Note: This function is available only in the day mode.
Select "ON" to rotate the images horizontally based on your installation situation when necessary.
Select "ON" to rotate the image 180° when necessary.
Click and drag the slider to adjust the level from 0 ~ 10 to decrease the noise shown in the dark environment.
Select "Auto" to automatically enable IR LEDs at night or in the dark environment, "On" to always enable IR LEDs, or "OFF"
to disable this function.
Select "On" to enhance IR LEDs performance.
Select the level for IR light to activate.
Process the current image to retain color balance over a color temperature range.
The options are: Auto, 2500K, 3200K, 4200K, 5800K & 9500K.
Sharpness enhances the clarity of image detail by adjusting the aperture and sharpening the edges in the pictures.
Hold and drag the slider to adjust the level of sharpness. The higher the value, the sharper the image.
Wide Dynamic Range (WDR) is used when users need to increase image recognizability in overexposure and dark areas.
The options are: LOW / MIDDLE / HIGH / OFF
Digital WDR is used to simulate the effect of WDR when users need to increase image recognizability in overexposure and
dark areas.
21
