B2
CONNECTIONS AND CONTROLS AXTON C209/C409
1
INPUT L+R
Low-level RCA signal input for connection to head-unit pre-out.
2
INPUT GAIN
Input gain/sensitivity control allowing the matching of the amplifier
input section to the head-unit (pre-out) output voltage.
3
FILTER FREQ. LPF
Crossover filter frequency control allowing the setting of the
Lowpass cut-off frequency between 40 and 240 Hz.
Note: This control is not active when the amplification mode switch
is in the ''Fullrange'' position!
4
Amplification Mode Switch
Depending on the selected switch setting the amplifier operates in
Fullrange, Highpass or Lowpass mode.
5
FILTER FREQ. HPF
Crossover filter frequency control allowing the setting of the
Highpass cut-in frequency between 40 and 240 Hz.
Note: This control is not active when the amplification mode switch
is in the ''Fullrange'' position!
28
All manuals and user guides at all-guides.com
Fuses for protection of the amplifier-internal electronics against
overload or faulty operation / wrong manipulation.
Power connection terminal to positive terminal of car battery.
Remote switiching contact for the automatic (remote) turn-on /
turn-off of the power amplifier from the head-unit's remote (or
antenna control) lead.
Power connection terminal to chassis ground or negative
terminal of car battery (-12 V)
Speaker output terminals for one stereo speaker pair or one single
speaker connected in bridged mode (e.g. subwoofer)
In bridged mode the minium speaker impedance is 4 Ohms!
Amplifier status-LED. Lit green when power is on.
Lit red when amplifier is in protect mode due to shorted speakers,
overtemperature etc.
6
FUSE
7
+12 V
8
REMOTE/REM
9
GROUND/GND
10
L
und
R
11
POWER LED
12
PROTECT LED
