CONNECTIONS AND CONTROLS AXTON C109
1
INPUT L+R
Low-level RCA signal input for connection to head-unit pre-out.
2
INPUT GAIN
Input gain/sensitivity control allowing the matching of the amplifier
input section to the head-unit (pre-out) output voltage.
3
FILTER FREQ. LPF
Crossover filter frequency control allowing the setting of the Lowpass
cut-off frequency between 10 and 300 Hz.
Note: This control is not active when the amplification mode switch is
in the ''Fullrange'' position!
4
AMPLIFICATION MODE SWITCH
Depending on the selected switch setting the amplifier operates in
Fullrange or Lowpass mode.
5
FILTER FREQ. SUBSONIC
Crossover frequency control allowing the setting of the Subsonic cut-
in frequency between 10 and 60 Hz.
6
FUSE
Fuses for protection of the amplifier-internal electronics against over-
load or faulty operation / wrong manipulation.
7
+12 V
Power connection terminal to positive terminal of car battery.
8
REMOTE/REM
Remote switiching contact for the automatic (remote) turn-on / turn-
off of the power amplifier from the head-unit's remote (or antenna
control) lead.
26
All manuals and user guides at all-guides.com
9
Power connection terminal to chassis ground or negative
terminal of car battery (-12 V)
10
Speaker output terminals for one or two subwoofers.
The minium speaker impedance is 2 Ohms!
11
Amplifier status-LED. Lit green when power is on.
12
Lit red when amplifier is in protect mode due to shorted speakers,
overtemperature etc.
13
Input for RJ11 jack, for the external bass level remote control.
14
Low level RCA signal output, to daisy-chain the RCA input signal to
another amplifier.
GROUND/GND
L
und
R
POWER LED
PROTECT LED
REMOTE PORT
OUTPUT L + R
