Pyrolino
| Children's wheelchair
4.9. Back rest
The hardness of the backrest covering can be adjusted to allow for
comfortable seating.
4.9.1. Backrest covering
30
The tighter you adjust the backrest covering, the harder the backrest
will feel. First remove the backrest padding that has been attached with
a hook-and-loop fastener (Fig. 30). Then you can pull the individual
straps so they are tighter or less tight (Fig. 31). To relieve certain areas
of your back, do not tighten the straps there as much. Now the back
cushion needs to be attached with the hook-and-loop fastener again.
4.10. Push handles
31
To make it possible for a companion to push the wheelchair comfortably,
the height of the push handles is adjustable. Loosen the lever screw
(Fig. 32) on the push handle. Pull the tube with the push handle to the
desired height (Fig. 33). The tighten the lever screw again to lock the
push handle.
4.11. Wheels and tyres
32
The spoked wheels are attached with a quick-release axle on the chassis
(Fig. 36). The Pyrolino has quick-release axles as standard (quick release
axles, see section 4.12).
33
54
Check that the wheels are securely seated
each time they are fitted.
Children's wheelchair |
4.11.1. Driving wheels
PU tyres (puncture-proof) with a size of 22" are mounted on your
Pyrolino as standard (Fig. 34). Pneumatic tyres are available as an
option. If they become worn or defective, the authorised a qualified
mobility dealer should be asked to perform the repair.
To ensure the optimum operating safety of the
brakes or wheelchair, there must be a tyre pressure
of 300-400 kPa (34 bar) with pneumatic tyres.
4.11.2. Steering wheels
PU tyres (puncture-proof) with a size of 8" are mounted on your Pyrolino
as standard (Fig. 35). Pneumatic tyres are available as an option. If
they become worn or defective, the the qualified mobility dealer should
be asked to perform the repair. To ensure the optimum operating safety
of the wheelchair, there must be a tyre pressure of 200-250 kPa (22.5
bar) for swivel-wheels with pneumatic tyres.
4.12. Quick-release axles
To make the transport of your wheelchair considerably easier, the
wheels are equipped with quick-release axles as standard:
•
Press the locking button of the quick-release axle with your finger
and pull off the wheel (Fig. 36).
•
When refitting the wheel, simply push the wheel back onto the
mount (Fig. 37). At the same time, press in the locking button as
well.
When attaching, make sure that the quick-release axle is inserted right
up to the stop. After attaching, check that the wheel is securely fixed
by pulling it towards you without operating the locking button of the
quick-release axle.
Bischoff & Bischoff GmbH | 01.06.2019
Pyrolino
34
35
36
37
55
