Astralpool MULTI-PARAMETRIC INSTRUMENT Manuel D'installation page 13

MAN
ORP CAL.
ORP CAL.
+475mV
ORP CAL.
+475mV
Wait 60"
At the end of each calibration point, the instrument will display the quality of the electrode as a percentage.
3.3.3 CL (CHLORINE) PROBE CALIBRATION
Connect the probe to the instrument as indicated in the electrical connections.
Select the CL probe from the Calibration menu.
CL CAL.
0.50 ppm
CL CAL.
1.20 ppm
CL CAL.
1.20 ppm
Wait 10"
In Automatic (MAN) mode:
Type: Man
Type: Auto
Type: Auto
Type: MAN
Type: MAN
Type: MAN
0000137242 Rev.3.1
•
Immerse the probe in the solution, insert the
solution's mV value and press Enter
•
Wait 60 seconds. When finished, the
instrument will display the probe's quality as
a percentage value.
•
Once the operation has concluded, a
message will appear indicating that the
calibration has been carried out successfully.
In Automatic (MAN) mode:
•
Use a reference instrument to read the
chlorine value.
•
Adjust the value shown on the display to
match the value read by the reference
instrument. Press Enter to confirm.
•
Wait 10 seconds for the calibration to
complete.
•
Once the operation has concluded, a
message will appear indicating that the
calibration has been carried out successfully.
11
