Advanced slave mode: If, in master/slave mode, you would like to control the slave units via
one of the standalone modes Auto or Loop, the control signal can be passed on with a delay
in up to 15 steps (ROOTPAR4: Slave Group 1–15, ROOTPAR6: 1–13). The delay is defined in the
submenu item Delay in the respective standalone mode and the delay factor in the slave menu
of the corresponding spotlight. This is a simple way to create a running light effect with a large
number of spotlights that are all the same model and which are all running the same software
version. This is otherwise only realisable with a suitable DMX controller and time-consuming
programming.
CLROOTPAR4
--------Menu-------
----Slave Group----
DMX Address
DMX Mode Standalone
DMX Delay 1–15
Slave
Standalone
Settings
Slave
Settings
System Info
Assign the spotlights to one of up to 15 groups as desired (ROOTPAR4: Slave Group 1-15,
ROOTPAR6: 1-13). Multiple spotlights may be assigned to a group. The group number is also the
factor by which the delay time set in the master unit is multiplied (see setup example).
Slave Group 0
No delay
Master unit
Mode
Auto Programme 1
Slave
Delay 0.5 s

SYSTEM SETTINGS (Settings)

Starting from the main display, press MODE to enter the main menu. Use UP and DOWN to select
the menu item Settings and confirm with ENTER.
--------Menu-------
DMX Address
DMX Mode
DMX Delay
Standalone
Slave
Settings
System Info
This will take you to the submenu for setting the submenu items (see table, select with UP and
DOWN, confirm with ENTER, change value or status with UP and DOWN, confirm with ENTER).
CLROOTPAR6
----Slave Group----
Mode
Standalone Gr 1
Slave
1–13
Slave
Settings
Main display
with group number
and delay time in
master unit
Slave Group 1 Slave Group 2
0.5 s delay 1 s delay
Mode Mode
Slave Slave
Gr 1 0.5 Gr 2
s
2.0
s
Slave Group 3 Slave Group 4
1.5 s delay 2 s delay
Mode
Slave
0.5 Gr 3 0.5 Gr 4
s s
Mode
Slave
Gr 3 0.5
s
Mode
Slave
Gr 3 0.5
s
Slave Group 5
2.5 s delay
Mode Mode
Slave Slave
0.5 Gr 5 0.5
s s
