Table of contents
Specifications on page 3
General information on page 3
Installation on page 6
User interface and navigation
on page 10

Specifications

Specifications are subject to change without notice.
Specification Details
Dimensions (W x D x H) 23 x 54 x 14 cm (9 x 21.3 x 5.5 in.)
Weight 4.5 kg (10 lb)
Power requirement 115 VAC, 60 Hz, 1.2 A
230 VAC, 50 Hz, 0.8 A
Fuse 1.6 A, 250 VAC, slow blow
Operating temperature 5 to 40 °C (41 to 104 °F)
Pollution degree 2
Protection class 1
Installation category II
Storage/operating humidity Maximum relative humidity is 80% for temperatures
up to 31 °C (87.8 °F), decreases linearly to 50%
relative humidity at 40 °C (104 °F)
Location Indoor or laboratory
1
Refer to the specific QuikChem method for lamp specifications for an application.
Operation on page 11
Maintenance on page 12
Troubleshooting on page 16
Replacement parts and accessories
on page 17
Specification Details
1
UV lamp -(most common) 354 nm (dark blue), Ushio type F6T5BLB (50717).
Use with the cyanide determination.
254 nm (clear), G6T5 (50775). Use with the total
nitrogen or the total phosphorous determination.
Certifications CE mark; listed by ETL to UL and CSA safety
standards (cETLus) for North America.
Warranty 1 year

General information

In no event will the manufacturer be liable for direct, indirect, special,
incidental or consequential damages resulting from any defect or
omission in this manual. The manufacturer reserves the right to make
changes in this manual and the products it describes at any time, without
notice or obligation. Revised editions are found on the manufacturer's
website.
Safety information
N O T I C E
The manufacturer is not responsible for any damages due to misapplication or
misuse of this product including, without limitation, direct, incidental and
consequential damages, and disclaims such damages to the full extent permitted
under applicable law. The user is solely responsible to identify critical application
risks and install appropriate mechanisms to protect processes during a possible
equipment malfunction.
Please read this entire manual before unpacking, setting up or operating
this equipment. Pay attention to all danger and caution statements.
Failure to do so could result in serious injury to the operator or damage
to the equipment.
Make sure that the protection provided by this equipment is not impaired.
Do not use or install this equipment in any manner other than that
specified in this manual.
