electrical connection
(see "Fig. 11: Connection of the appliance socket").
Fig. 11: Connection of the appliance socket
→
③ on the appliance socket and remove.
Loosen cap screw
note!
functional failure due to buckled connector lugs preventing
re-installation of the contact insert!
• Carefully remove the contact insert and take care to ensure that
the connector lugs do not become buckled.
→
④ and remove contact insert ②.
Loosen screw in the cap
→
Lead cable through coupling nut
24
All manuals and user guides at all-guides.com
Pos. designation of parts
1 Flange sealing
2 Contact insert
3 Cap screw
4 Cap
5 Pressure ring
6 Flat seal
7 Collet
8 Coupling nut
⑧.
english
Type 2 000, 2002, 2012
Option: Electrical position repeater
→
Make connection as per circuit diagram
(see „Fig. 12: Electrical WAFitsching").
→
Max. rating:
5 A at 250 V AC
0,25 A at 250 V DC.
Fig. 12: Electrical WAFitsching
→
② in the cap ④ and screw on.
Place contact insert
→
Screw on appliance socket with cap screw
seating of the flat seal ⑥.
→
Test valve for function and leaktightness.
2030, 2031; 2032, 2033
Assignment: 1.
Input
2. Break contact
3. Make contact
③, assuring proper
