BM 2610034445 03-14_FNH180 3/27/14 11:52 AM Page 22
3. Locate pin #2. To remove, use pin #1 and
push pin #2 from either side until enough of
the pin has been exposed. Remove
completely. Place both pins in secure place
for reassembly (Fig. 33).
4. Remove Driver Sub Assembly. Holding tool
securely with one hand, use other hand to
remove driver sub-assembly by grabbing
both sides and then pull directly back

(Fig. 34).

5. The Driver Sub Assembly consists of 5 parts

(Fig. 35):
A) Driver Block Assembly (1)
FIG. 33

PIN #2

PIN #1
FIG. 34
FIG. 35
B
B
All manuals and user guides at all-guides.com
B) Guide Rails (2)
C) Guide Sleeves (2)
D) Return Frame (1)
E) Rubber Cords (2)
6. Remove rubber cords and pull driver block
7. Remove guide sleeves away from driver
8. If rubber bumper and guide rail become
C
D E
C
-22-
assembly away from return frame and guide
rails (Fig. 36).
block assembly (Fig. 37).
detached from return frame, re-attach
rubber bumper and guide rail as shown
(Fig. 38).
FIG. 36
FIG. 37
FIG. 38
