Complete Installation - KitchenAid KUDS40FVPA Instructions D'installation

Check side attachment
6
plastic
button
If securing with a side attachment, check that sides of door
do not rub against the screw heads. If they do, dishwasher
must be re-centered. When dishwasher is properly centered,
replace plastic buttons.
7
Remove towel and replace
lower dishwasher rack
Remove towel from dishwasher. Reinstall the lower
dishrack.
If needed, see website for animated representation
of this step. Visit www.kitchenaid.com/anchoring under
FAQ tab.

Complete Installation

1 Reinstall access panels
Insulation
(on some models)
Access
panel
Lower
panel
24
Insulation
Grounding Grounding Gr ounding
clip clip clip
Check that grounding clip is attached to the lower panel.
Position the lower panel behind the access panel. On some
models there is insulation on the access panel which must
fall behind the insulation on the lower panel.
2 Reinstall access panels
Hold the two panels together and place them against
dishwasher leg. Using a Philips or 1/4" screwdriver, reinstall
the screws through the holes in the access panel and the
slots in the lower panel.
3 Check lower panel edge
Check that the lower edge of the lower panel contacts
the floor. Adjust if necessary.
4 Tighten screws
Tighten access panel screws.
