Move Dishwasher Into Cabinet Opening - KitchenAid KUDS40FVPA Instructions D'installation

2
Break end of bracket
score line
Break off the end of the bracket along the scored line.
With another person holding the rear of the dishwasher
to keep it from tipping, open dishwasher door and place
towel over pump assembly and spray arm of dishwasher.
This will keep screws from falling into pump area when
you are securing dishwasher to cabinet.
3
Insert plastic buttons
plastic
button
Push the plastic buttons out of the side of the tub.
NOTE: Save the buttons to cover the holes after
dishwasher is installed.
4
Reinstall bracket
bend
tabs
Push bracket into slot on the side of dishwasher, and
bend tab in toward the side of the dishwasher so that it
keeps the bracket in place. Repeat this step for the other
side of the dishwasher.
NOTE: Do not attach the dishwasher. This will be done
later.
18
Move Dishwasher into Cabinet
Opening
WARNING
Excessive Weight Hazard
Use two or more people to move and install
dishwasher.
Failure to do so can result in back or other injury.
1 Stand dishwasher upright
Using two or more people, stand dishwasher upright.
NOTE: Do not install kickplate until instructed.
2 Move dishwasher close to
cabinet opening
IMPORTANT: Double check correct placement of utilities.
Grasp the sides of the dishwasher at the edges of the
door panel. Tilt dishwasher backwards on wheels and
move dishwasher close to cabinet opening.
NOTE: Do not push on the front of the panel or on the
console. Panel or console may dent.
Helpful Tip: Temporarily tape utilities to the floor in the
locations shown to prohibit them from moving when
dishwasher is moved into the cabinet opening.
Drain
hose
Direct wire
only
Water
line
Cable
