Using power assisted pedalling
06
- Press the button "T4" once or more times
to select the pedalling assistance level; the
function activates immediately.
- Press button "T5" to decrease the pedalling
assistance level.
6.e - "Push help" function
- This function allows to help the bicycle push in
particular situations (for example: at the start
of a slope, or on an uneven terrain, etc.).
The function can be used both while walking
alongside the bicycle and when riding.
- To activate the function it is necessary to keep
the button "T6" pressed for more than three
seconds; the function deactivates when the
button is released.
- When the function is active, the "b" symbol ap-
pears in the top right corner of the display.
6.f - USB connection
- The tool is equipped with an Usb port protect-
ed by a rubber cover.
- It is possible to connect an external device
(mobile, smartphone, mp3 player etc.) to the
Usb port.
EN_30
-
T4
T5
-
To disable the assisted pedalling:
- Press button "T5" once or more times until the
graphic aside is selected; the system turns
off.
In the event of a prolonged use in severe
conditions, the motor will be powered in pro-
gressively reduced way in order to not exceed
the safety temperature.
o
min.
MAX
T5
T6
Once the link has been performed, the new
connection is shown on the device.
The charging current is 5 ampere.
Fantic Motor takes no responsibili-
ty for eventual damages caused to
the external device connected to
the Usb port.
To correctly disconnect the device, please refer
to the instructions supplied together with the
device itself.
T4
b
Ed. 1 - 03/2019
