Technical Specification - SOUNDMASTER RR18SW Manuel D'instructions

1. Set the Function switch to "USB" position.
2. Insert a USB device into the USB port or a SD memory card into the SD card slot.
3. To fast forward, press the "SKIP FORWARD" button in and release.
4. To rewind, press the "SKIP REWIND" button in and release.
5. To stop the playback, press the "PLAY/PAUSE/RECORD" button.
RADIO to USB/SD RECORDING
1. Set the Function switch to the RADIO position.
2. Insert a USB device or SD memory card and press long the "PLAY/PAUSE/ RECORD"
button to record the current radio program on the USB device or SD memory card.
3. When you have finished recording, press long the "PLAY/PAUSE/RECORD" button.
CASSETTE to USB/SD RECORDING
1. Set the Function switch to the "TAPE/OFF" position.
2. Insert a USB device or SD memory card and press long the "PLAY/PAUSE/RECORD"
button to record the current cassette playing on the USB device or SD memory card.
3. When you have finished recording, press long the "PLAY/PAUSE/RECORD" button.
DELETE A TRACK
1. Set the Function switch to the "USB" position.
2. Insert a USB device into the USB port or a SD memory card into the SD card slot. The
playback starts automatically.
3. Select the desired track with the "USB/SD SKIP FORWARD" or "USB/SD SKIP REWIND"
button.
4. Press and hold the "USB/SD SKIP FORWARD / DEL" button. The track will be deleted.
5. To delete more tracks, repeat steps 3 and 4.
Power supply
Battery supply
Max. power consumption
Audio power output
Technical changes and misprints reserved
Copyright by Woerlein GmbH, 90556 Cadolzburg,
Duplication only with the permission of Woerlein GmbH
USB/SD CARD OPERATION
USB/SD-CARD RECORDING

TECHNICAL SPECIFICATION

: AC 230V~ 50/60Hz
: 4x DC 1.5V UM-1 / "D" size (not included)
: 10W
: 1x 3W RMS
www.soundmaster.de
4
RR18 / English Instruction Manual
