Malfunction
Corrosion on air noz-
zle threading, material
passage (cup connec-
tion) or paint spray
gun body.
Spray medium es-
capes behind paint
needle packing.
Paint spray gun drips
at air nozzle pin ("Air
nozzle pin").
12. Disposal
Dispose of completely emptied paint spray gun as recyclable material.
To prevent harming the environment, properly dispose of any remaining
spray medium and stripping agent separately from the paint spray gun.
Comply with local regulations!
13. After Sale Service
Please ask your SATA dealer for accessories, spare parts and technical
support.
14. Accessories
Part No. Description
6981 Quick coupling nipple G 1/4" (female thread)
27771 Air micrometer 0 – 845 with pressure gauge
64030 SATA cleaning set
53090 Air hose
Cause
Cleaning fluid (aque-
ous) remains too long
on gun.
Unsuitable cleaning
fluids used.
Faulty or missing paint
needle packing.
Paint needle dam-
aged.
Paint needle dirty.
Foreign body between
paint needle tip and
paint nozzle.
Nozzle set damaged.
Corrective action
Have gun body re-
placed. Read and follow
cleaning instructions
(see 10).
Replace paint nozzle
packing (see 9.3).
Replace nozzle set
(see 9.1).
Clean paint needle.
Read and follow
cleaning instructions
(see 10).
Clean paint nozzle and
paint needle. Read and
follow cleaning instruc-
tions (see 10).
Replace nozzle set
(see 9.1).
Quan-
tity
5 ea.
1 ea.
1 set
1 ea.
US
569
