Operating Instructions SATAjet 100 B F (RP / HVLP), B P
EN
Malfunction
Spray pattern too
small, slanted,
one-sided or split.
Round / flat fan control
not working – control
can be regulated.
Round / flat fan control
cannot be regulated.
Spray gun does not
shut air off.
Material splutters in
gravity flow cup.
146
All manuals and user guides at all-guides.com
Cause
Air cap holes clogged
with paint.
Damaged fluid tip
(fluid tip aperture).
Air distribution ring not
correctly positioned
(pin not in hole) or
damaged.
Round / flat fan control
has been turned coun-
terclockwise over the
limit; spindle loose in
gun thread.
Air piston seat
clogged.
Air piston worn.
Atomising air gets into
gravity flow cup via
paint channel. Fluid
tip not tightened suf-
ficiently. Air cap not
screwed on complete-
ly, air circuit clogged,
seat defective or noz-
zle set damaged.
Corrective Action
Clean air cap. Heed
cleaning instructions
(see chapter 10).
Check fluid tip for dam-
age and replace nozzle
set if necessary (see
chapter 9.1).
Replace air distribution
ring (see chapter 9.2).
Unscrew round / flat
fan control using the
universal spanner and
make it work again or
replace it completely
(see chapter 9.6).
Clean air piston seat.
Heed cleaning instruc-
tions (see chapter 10).
Replace air piston and
air piston packing (see
chapter 9.4).
Tighten, clean or re-
place parts.
