ENGLISH
[6] Function settings
• Set the LINE-1 and LINE-2 function names and turn the analog
recording output (REC OUT) on or off.
• When used in combination with the D-M31 series, set according to
the components being used and make system connections for
convenient system functions.
• It is also possible to assign the D.AUX digital input to LINE-2.
1 If you are not at the system setting changing menu screen,
read step 1 and 2 on page 33.
2 At the system setting changing menu screen, use the
1 cursor buttons to select "FUNCTION ASSIGNMENT", then
press the ENTER button.
Remote control unit
• The input function setting screen appears.
Use the • and ª cursor buttons to select the item to be set,
3
then use the 0
LINE-1 Function name selection ("MD" by default)
B
AUX
LINE-2 Function name selection ("TAPE" by default)
B
LINE-1/LINE-2 REC OUT
B
: Set whether to turn the recording output during playback in
the Dolby Virtual Speaker mode when the function set to
DVD or the D.AUX exclusive digital input on or off.
On : The signals are output in stereo. (Factory default)
Off : The signals are not output. (Recording is not
possible.)
4 Press the ENTER button to enter the
settings.
• The next screen in the system setting
changing menu appears.
38
ENTER
Remote control unit
1
and cursor buttons to make the settings.
MD/CD-R
CD-R MD
TAPE AUX D.AUX
Remote control unit
Input function settings
• LINE-1 and LINE-2 can be set as described below.
LINE-1 : "MD", "CD-R", "MD/CD-R" or "AUX" can be
selected.
("MD/CD-R" can only be set when a system MD
recorder, cassette deck and CD recorder are all
connected and system operations are being used.)
LINE-2 : This can be set to "TAPE", "MD", "AUX" or "D.AUX".
(Set "D.AUX" to use the D.AUX digital input in
combination with the LINE-2 analog input.)
• The setting for LINE-1 has priority. Once a function is set for
0
and
LINE-1, it is not possible to set the same function for LINE-2. (For
example, if "MD" is selected for LINE-1, "MD" is no longer
offered as one of the choices for LINE-2.)
LINE-1/LINE-2 analog recording output setting
• Normally set this to "On".
• With the DVD or D.AUX exclusive digital input function, set this
to "Off" if noise is generated when playing sources with high bit
rates in the Dolby Virtual Speaker mode.
• This setting is only valid in the Dolby Virtual Speaker mode for the
DVD or D.AUX exclusive digital input function. (In surround
modes other than the Dolby Virtual Speaker mode and with other
input functions, analog recording signals are output, regardless of
this setting.)
• Analog recording is not possible when this is set to "Off". To
record, use a mode other than the Dolby Virtual Speaker mode
(stereo, for example).
(4) After changing the system settings
• This completes the procedure for changing the system settings.
Once the speaker settings, delay times and channel levels have
been set, there is no need to change the settings again unless the
connected AV components or speakers are changed or the
speakers are moved to different positions.
• DVD auto power off and function settings as necessary.
1 At the system setting changing menu
screen, press the SETUP button.
• The new settings are entered and the
on-screen display turns off.
The setup procedure can be quit at any point by pressing this
button.
NOTE:
• When system settings have been changed with the system
setting changing menu and a speaker system is selected with
the quick system settings, the speaker settings and delay time
settings are changed to the values preset for the quick system
settings.
ENTER
SETUP
Remote control unit
