LOCATION OF THE BUTTONS

Control panel

Display window
12
p q
1
(standby/on/attenuator) button
2
+/– button
3
LOUD button
4
MO (monaural) button
RND (random) button
5
Display window
6
0 (eject) button
7
CD button
8
FM button
9
AM button
p
SEL (select) button
q
4 ¢ buttons
/
• Also functions as SSM buttons when
pressed together.
w
Number buttons
e
DISP (display) button
r
RPT (repeat) button
SCAN button
t
SCM (sound control memory) button
y
(control panel release) button
4
u i
g
f
3 4 5
o ;
h
w
Display window
u
Volume (or audio) level indicator
Equalization Pattern indicator
i
Tuner reception indicators
MO (monaural), ST (stereo)
o
RND (random) indicator
;
RPT (repeat) indicator
a
"SCM" indicator
s
LOUD indicator
d
Sound mode indicators
BEAT, SOFT, POP
f
CD indicator
g
Band indicators
FM1, FM2, FM3
AM
h
Main display
j
CD IN indicator
a s d
j
6 789
e r t y
