GB
Faults on the machine or its guards, safety
devices and blade have to be reported to the
person in charge as soon as they are
discovered.
Use only the transport devices to move the
machine. Never use the guards for handling and
moving the machine.
While you are moving the machine it is best to
cover the top part of the blade, e.g. with the
guard.
Do not cut rebates or grooves without fitting a
suitable guard, e.g. a tunnel-type guard, over the
saw table.
Circular saws must not be used for slotting jobs
(cutting grooves which end in the workpiece).
Important:
Risk of injury!
Never reach into the running
saw blade.
Wear goggles
Wear ear-muffs
Wear a breathing mask
Noise emission values
Idle
Sound pressure level LPA 104,5 dB(A)
Sound power level LWA 114,1 dB(A) 105,2 dB(A)
The quoted values are emission values and not
necessarily reliable workplace values. Although there
is a correlation between emission and immission
levels it is impossible to draw any certain conclusions
as to the need for additional precautions. Factors
with a potential influence on the actual immission
level at the workplace include the duration of impact,
the type of room, and other sources of noise etc.,
e.g. the number of machines and other neighboring
operations. Reliable workplace values may also vary
from country to country. With this information the
user should at least be able to make a better
assessment of the dangers and risks involved.
20

5. Technical data

AC motor
Power P
Idle speed n
0
Cutting-off wheel
Number of teeth
Table size
Table width extension, left/right
Table length extension, rear
Cutting height max.
Height adjustment
Tilting saw blade
Extractor socket
6. Before putting the machine into
operation
Unpack the bench-type circular saw and check it
for damage which may have occurred in transit.
The machine has to be set up where it can stand
firmly, e.g. on a work bench, or it must be bolted
to a strong base.
All covers and safety devices have to be
properly fitted before the machine is switched
on.
It must be possible for the saw blade to run
freely.
When working with wood that has been
processed before, watch out for foreign bodies
such as nails or screws etc.
Before you actuate the On/Off switch, make sure
mode
that the saw blade is correctly fitted and that the
95,5 dB(A)
machineʼs moving parts run smoothly.
Before you connect the machine to the power
supply, make sure the data on the rating plate is
the same as that for your mains.
7. Assembly
Important! Pull out the power plug before
carrying out any maintenance, resetting or
assembly work on the cutting-off machine!
7.1 Assembling the base frame (Fig. 17/18)
Turn the saw upside down and place it on the
floor.
Use the hex screws and nuts to fasten the four
05.06.2008 8:25 Uhr Seite 20
230V - 240V 50Hz
S1 1500 W S6 40% 1800 W
5700 min
Ø 250 x Ø 30 x 2.4 mm
24
625 x 440 mm
625 x 250 mm
400 x 440 mm
73 mm/90°
53 mm / 45°
infinite 0 -73 mm
infinite 0° - 45°
Ø 36 mm
