WS1G8R2 fRONT- / BACk PANEL:
1
1
POwER ON / Off.
2 SET BUTTON
Push and hold for 1 second to access menu items
3
VOLUME / VALUE
Up and Down buttons
4 ASC BUTTON
Frequency sync via infrared
5 INfRARED INTERfACE
1
1 TNC SOCkETS ANTENNA A / B
2 BALANCED XLR OUTPUT CHANNEL 1
BALANCED XLR OUTPUT CHANNEL 2
3
4
BALANCED XLR MIX OUTPUT
This output provides a mix of both receivers
audio signals. For individual volume control adjust
the volume on the front panel of each receiver
separately.
8
6
L
AUTO VOLUME
7 8 9
L
AUTO VOLUME
5 4
2
3 5
4
6
ANTENNA A / B LEDS
Indicates whether antenna input A or B is active
7
6 SEGMENT Rf (RADIO fREqUENCY) SIGNAL
LEVEL METER ANTENNA INPUT A / B
8 7 SEGMENT AUDIO LEVEL METER
9 ILLUMINATED MULTIfUNCTIONAL DISPLAY
10
HEADPHONES OUTPUT
6.3 mm stereo jack.
11 HEADPHONES VOLUME.
3 2 6
5 UNBALANCED MIX 6.3 MM jACk OUTPUT
This output provides a mix of both receivers
audio signals. For individual volume control adjust
the volume on the front panel of each receiver
separately.
6
DC SOCkET. ONLY USE THE SUPPLIED POwER
ADAPTER
L
AUTO VOLUME
10 11
L
AUTO VOLUME
