² " ": key-lock icon, when this icon appears, it means that the key operation is disabled.
Note: the key-lock status can be set at any screen view by combining the given keys. During key-lock status, all
key operations are disabled except Power button and combination keys for unlocking operation.
² " ": net connection icon, indicates that the device is connected to the network. If the device is disconnected
from the network, then the icon will disappear.
²
" ": battery voltage indicator.
² "PLETH": indicating the displayed waveform is plethysmogram.
Waveform area:
² "II": ECG lead.
² "x1": ECG waveform gain.
²
"PI% 12.3": the label and value of perfusion index. This item is displayed only when "Setup Menu→SpO2→
PI Display" is set as "ON".
Note: PI function is optional, please refer to the monitor in your hand, we will not cover it again.
² "37.5℃"/"-- ℃": the measured temperature value. This function is optional.
SpO2:
² " " (When Nellcor SpO
SatSeconds. Here "50" is the SatSeconds setting value. "
filled, an alarm will be triggered. The monitor shall display SatSeconds icon when it is activated via SpO
setting menu. More information, please see 4.9.2 SpO
² " " (Appears only when Nellcor SpO
the measuring site, if the monitor detects pulse beat, the Pulse Search Icon will appear until the first valid
reading of SpO
loss-of-pulse.
²
" " (Appears only when Nellcor SpO
appear continuously during periods of strong motion artifact interference.
If the accessories are connected incorrectly or disconnected from the monitor, the message "Probe off" and (or) "ECG
lead off" will appear on the screen.
NIBP list area:
When blood pressure measurement is taken, the data display area displays the recent 4 groups of data, the form is as
shown in figure 4.2.
² "Time": the measuring time.
² "SYS/DIA/MAP": systolic/diastolic/arterial mean pressure.
²
"PR": the measured pulse rate from the blood pressure measuring channel or the pulse rate value from
oximetry measuring channel. The PR value from oximetry will take priority in the display.
² "SpO2": oxygen saturation (SpO
² "TEMP": the temperature value. This function is optional.
² "HR": the heart rate.
Note: 1. If the device is re-started, the data in the list data area will be cleared.
2. Invalid values will be displayed as "--"
Prompt Info. area:
² "MAP over-limit": displays a message for current alarm event indicating that the measured MAP value exceeds
the preset value.
is configured AND setting SatSeconds value is not zero): The icon of
2
is available. The Pulse Search Icon will appear continuously under the condition of
2
for short).
2
" is the circle icon filling. When the circle is fully
Setup.
2
is configured): Pulse Search Icon. After SpO
2
is configured): Interference Icon. The Interference Icon will
2
22
2
sensor is applied on
2
