Installation of the stove on a floor support (optional)
To install the appliance on the support, proceed as follows:
step action
1 Fix the slide to the floor support using the screws supplied with the support.
2 Remove the two telescopic guides and insert the fireplace, fixing it with the wing nuts (see previous paragraph)
3 Check the correct functionality of the coupling and the release.
You can hear when coupling occurs, as it makes a "clicking" sound.
1
The stove is supplied with a micro-switch placed to the side of the rear jamb on the right. After dismantling/re-assembly operations of
the stove on the base, check the micro-switch activates following insertion of the stove.
