Control buttons and functions
Button
1
2
3
(optional)
4
(optional)
5
(optional)
6
(optional)
LED A
(optional)
LED B
(optional)
LED C
(optional)
Operation Manual (Version: B)
Function
Main switch /
Emergency stop
Deck up
Side switch ON/OFF
Auto Return
Door open/close/ stop Only possible when door is controlled by
Inside traffic lights
Fault/status LED (red) This red LED will light up if a fault has
status LED (green)
status LED (green)
Description
Turns power to the control box on or off.
The switch can be locked with a padlock in the
off position.
Push for normal operation.
Push briefly to release certain functions.
Used for options like inflatable shelter and
BDC.
Returns the deck to parked (standby) position.
control box.
Signals if loading and unloading is allowed
(=door open, leveller in truck) or not.
occurred.
When the fault is corrected the LED will go
out.
The green LED indicates that the leveller can
be operated.
The green LED indicates that the door can be
operated.
