Ducting Configurations
Front Exhaust with DBI-600A Blower (through cabinet)
Electrical Panel
Front Exhaust with DBI-600A Blower and
Recirculating Kit
DBI-600A Blower
Electrical Panel
ZRC-00LF (Recirculating Kit)
(continued)
DBI-600A Blower
8" Round Elbow
Downdraft
8" Straight Duct
Downdraft
8" Straight Duct
Front Exhaust with DBI-600A Blower (through
cabinet) and Recirculating Kit
DBI-600A Blower
Electrical Panel
8" Round Elbow
ZRC-00LF (Recirculating Kit)
Refer to ZRC-00LF manual for further recirculating kit installation
instructions .
6
Planning
Downdraft
8" Straight
Duct
