Installation instructions, for professionals only p. 16/32
WARNING!
Personal injury
● The clamping connections may only be installed by a qualified electri-
cian or similarly qualified person.

5.3. Connecting the foil sensor (optional)

Clamp the foil sensor line on the 2-pin foil sensor plug to FF accord-
ing to Fig. 6: Connection area for sensor/control unit on page 14.

5.4. Connecting the HV input (enable input)

The input becomes active by applying alternating current
(230 V / 50 Hz). The input is connected using 2-pole HV plug according
to Fig. 7: Connection area for 230 V on page 15.
Refer to chapter 6.7. HV input (enable input) on page 24to follow
the exact step-by-step procedure.
5.5. Connecting the safety temperature limiter
(optional)
When using infrared heaters and infrared plates without intrinsic
safety, a safety temperature limiter is required and must be connected!
The STB line is connected as shown in Fig. 6: Connection area for
sensor/control unit on page 14 to the STB connection.

5.6. Connecting the infrared heater / infrared plate

Connect the infrared heater/infrared plate to the connection provided
according to Fig. 7: Connection area for 230 V on page 15. Observe
the instructions for this in the operating instruction manual.
