3. Ceiling Fan Assembly
Carefully turn the partially assembled Ceiling Fan to
expose the upper housing and place onto the foam
pad in preparation of it's hanging system.
3.5
Separate, untwist and unkink the three 80" Motor Leads.
Route the three 80" Black, Blue, and White Motor Leads
through the Downrod (Figure 5).
3.6
Loosen the two Phillips Head Set Screws in the Motor
Coupler for installation of the Downrod (Figure 6).
Seat the Downrod in the Motor Coupler (Figure 6).
Rotate and align the Downrod holes with all the holes in
the Motor Coupler (Figure 6).
(Continued)
LEADS (UNTWISTED)
Figure 5
DOWNROD
MOTOR COUPLER
LOOSEN PHILLIPS
HEAD SET SCREWS (2)
Figure 6
7
THREE 80" MOTOR
DOWNROD
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: CF825
