This unit can also receive FM band radio stations and display RDS data (where broadcast).
•
Press "SOURCE" button to select FM,
•
Press "TUNE ▼/▲" button tune to FM station by 50 kHz steps, press and hold the "TUNE
▼/▲" button (2 sec.) to start the FM station search. The search is stopping at the next
available station.
•
Press the "SCAN button" to activate the preset automatic store function.
The radio will search and the tuning frequency will be displayed whilst searching.
When a usable station is detected the radio will stop tuning and play the station.
If RDS data is present, the station name and scrolling radio text will be displayed.
If RDS data is not present, the tuned frequency will be displayed.
DISPLAY MODE OPTIONS
The bottom line of the display can be switched to show different items of information that may
be transmitted with a FM station.
Press the" /INFO" button repeatedly to change the information displayed while playing a FM-
RDS radio station.
The full range of display options are shown below.
Some stations may not broadcast all of these options.
Audio mode > Radio Text > Program Type > Signal Strength > Time/ Date > Frequency
FM MONO/ STEREO
During FM mode, press the "SELECT" button repeatedly to set audio mode in STEREO or
MONO.
This player can playback CD, CD-R and CD-RW with CDDA, MP3 and wma audio format.
•
Press "SOURCE" button to select CD
Loading a disc:
•
Press button to open the CD door.
•
Gently place a disc on the center spindle with the label up side.
•
Once in place, press the center of the disc until it clicks into place on the turntable.
•
Close the CD door.
After a few seconds the disc will read and the disc data.
For the CD disc data display:
For the MP3 disc contains folder:
F: folder number, T: total tracks number
FM RADIO
CD OPERATION
