- The computer automatically detects a new device. Insert the supplied software CD into
a CD drive and follow the installation instructions on the screen. Let the computer
search for the new driver automatically.
- After successful installation, you may start the software.
- To deactivate the USB interface, press the button for backlight and laswer (8) in MIN,
MAX, DIF or AVG mode until the USB symbol (25) vanishes from the display.
When the USB interface is activated, the infrared and measured contact temperature val-
ues may be transferred to a computer. In connection with the LOCK function and the includ-
ed software, this enables you to establish a long-term temperature record. For further infor-
mation, refer to the software help menu.
Contact temperature measuring function
In addition to the infrared measuring function, the devices have a contact temperature measuring func-
tion. In addition to the included wire temperature sensor, all traditional type K temperature sensors with
a mini plug can be connected to the devices.
When you connect a type K temperature sensor with a mini plug to the type K temperature sensor sock-
et (2), "TK" will be displayed in MIN, MAX, DIF or AVG mode when the device is switched on. When the
measuring button (5) is pressed, the measured contact temperature is displayed in the right secondary
display (21).
Observe that contract temperature measurement must only be conducted for standing
objects that are free of voltage. Also observe that only contact temperatures up to the sen-
sor's permissible temperature are allowed. The permissible temperature of the included
wire sensor is at max. 150°C (max. 10 seconds).
Setup menu
The setup menu allows you to select, activate or set the different functions of the device. The following
illustration is a schematic of the settings menu. Use the "MODE" button (6) to navigate within the menu.
Use the "up" (4) and "down" buttons (7) to make adjustments.
* MEMORY only for IR 1200-50D USB and IR 1600-50D USB
