KNOWINg YOUr MITEr SAW
10
11
12
13
14
15
16
1. Handle
2. Lock-Off Switch
3. Trigger Switch
4. Laser Switch
5. Light Switch
6. Carrying Handle
7. Upper Blade Guard
8. Lower Blade Guard
9. Motor
10. Dust Bag
6
7
8
9
17
30
11. Sliding Rails
12. Slide Lock Knob
13. Hold Down Work Clamp
14. Table Extension
15. Extension Lock Knob
16. Base
17. Miter Table
18. Miter Angle Pointer
19. Throat Plate
20. Bevel Lock Handle
4
3
5
26
18
19
20
27
28
29
21. Detent Lever
22. Miter Lock Handle
23. Fixed Miter Fence
24. Sliding Miter Fence
25. Laser
26. Light
27. Saw Head Lock Knob
28. Bevel Scale
29. Spindle Lock Button
30. Miter Scale
1
2
25
24
23
22
21
FIG 1
9
