OPERATINg INSTRUCTIONS

Navigating Menus and Onboard Reporting

While the SmartLink Module is attached, it will collect important data about how the device
is being used and what kind of therapy it is delivering for you. Much of the information that is
collected is available to you through the onboard menu on your CPAP display. The previous
table shows how to navigate through the menus.
When the SmartLink is connected correctly, the display on the
CPAP will show this message.
in the module before attaching the module to the CPAP, then
card detection messages may be displayed.
To enter the SmartLink menu, press the LEFT and RIGHT Arrow
keys on the CPAP keypad at the same time. To exit the SmartLink
menu, press the same key sequence again or simply turn the
CPAP off and on.
The next menu item is the "Quick View" submenu. To enter the
Quick View submenus, press the DOWN Arrow key.
pressing the UP Arrow key at the Quick View menu will exit
the SmartLink menu.
Quick View Submenu Navigation:
Navigate through the Quick View submenu by using the UP or DOWN Arrow keys to
change between 1, 7, or 30 day averages and RIGHT or LEFT Arrow keys to cycle through
the items within the selected time period.
The average pressure provided during the selected time period
(1, 7, or 30 days).
The Apnea/Hypopnea Index (AHI) is the number of apneas and
hypopneas detected per hour. The average AHI is displayed for
the time period selected (1, 7, or 30 days).
The Leak Percentage is the percentage of therapy time that the
system leak was above 95 Liters/Minute (L/Min). A system leak
above 95 L/Min, in most cases, is considered excessive and is
usually an indication of a poor mask fit that should be corrected
8 A-DV5M-1
NOTE
–if a data card is inserted
operATIon
SmartLink Module
Ready for Use
SmartLink Menu
Press   To Exit
Quick View Menu
NOTE
Press 
–
Average Pressure
30 day avg 10.1
AHI
30 day avg: 2.0
Leak %
30 day avg: 5.0
