8. PART LIST
REF. No.
DESCRIPTION
1
Circlip ring 17x1
3
Upper band saw wheel assembly
4
Upper bearing shaft
5
Wheel carrier bracket
6
Spring washer M16
7
Hexagonal nut -M16x1.5
8
Special Screw for tension
9
Starlock w/o cap Rd10
10
Cylindrical pin 11x100
11
Tension bracket
12
Sloted inset
13
Saddle washer
14
Lock housing
15
Nylon washer
16
Hexagonal nut M22x1.5
17
Tongue lock
18
Serrated lock washer 6mm
19
Hexagonal bolt -M6x10
20
Leaf spring
21
Door-upper assembly
23
Lamello plug
24
Blade tension knob
25
Blade tensioner
26
Flat washer 8 mm
27
Hexagonal head screw M8x16
28
Blade tracking knob
29
Wing nut M8
31
Tension bracket frame
32
Flange nut M8 galvanised
33
Frame-Bandsaw
35
Pan head taping screw 4.2x16
36
Serrated lock washer 5 mm
37
Plate
38
Carriage bolt M8x20
39
Bolt guide
40
Hexagonal bolt -M6x20
42
Guide bracket
43
Serated lock washer 6 mm
44
Hexagonal nut M6
45
Saw blade guide assembly
46
Slide
48
Guide adjust screw
49
Grooved ball bearing 80018
50
Flat washer 6 mm
51
3-roller guide ass'y
53
Bolt guide, small
54
Screw socket set M6x12
55
Guide shaft
56
Upper guide mount
57
Flat washer 8 mm
58
Hexagonal nut M8, self locking
60
Bearing mount cylinder w/cap
64
Bearing mount cylinder
REF. No.
DESCRIPTION
65
Flange nut M8 galvanised
69
Door-lower assembly
70
Hexagonal nut M4, self-locking
71
Flat washer 4 mm
72
Saw blade guard
73
Hexagonal screw -M4x12
74
No-volt switch
75
Carriage bolt M8x100
76
Brush
77
Spacer bush 8x50
78
Lower band saw wheel assembly
79
Grooved ball bearing 80101
80
Tension wheel
81
Circlip ring 12x1
83
Sliding shaft
85
Hexagonal nut -M20x1.5
86
Lower bearing shaft
87
Poly-v-belt
88
Motor belt pulley
90
Hexagonal screw -M6x16 galvanised
91
Spring washer 6 mm
92
Set collar 10 mm
94
Disk washer 20x10.2x0.8
95
Crank
96
Suction connector Rd 100
100
Hexagonal flat nut-M6 galvanised
101
Crank handle
102
Cap screw M6x55
103
Motor 1 Kw 220/240V1~
104
Pin guide set
105
Lower guide support
109
Rip fence carrier
112
Knurled thumb screw M6x25 galvanised
113
Knurled nut M6
114
Washer flat 6 mm
115
Carriage bolt M6x40
116
Fence extrusion
117
Bolt guide
118
Carriage bolt M8x50
119
Table
120
Table insert
123
Scale-metric
124
Rip fence carrier extrusion
125
Hexagonal nut M6
130
Wing nut M8
134
Glide piece
135
Table trunion upper
136
Serrated lock washer 8 mm
137
Hexagonal screw M8x20
140
Table trunion lower
200
Band saw tyre 350x2.5x20
- 12 -
GB
