BML-M0 -I -A
Magnetic Tape – Incremental Magnetically Coded Position Measuring System
7

Type code breakdown

7.1

Type code breakdown for tape without reference point

Magnetic tape
Construction
02 = linear, incremental, 1.55 mm thick, with adhesive layer
03 = linear, incremental, 1.35 mm thick, without adhesive layer
07 = linear, incremental, 1.43 mm thick, with adhesive layer
Type
I = Incremental
Pole width
3 = 1 mm
4 = 5 mm
5 = 2 mm
6 = 10 mm
Accuracy class
4 = 8 µm (only with 1 mm pole width)
5 = 18 µm (only with 1 mm, 2 mm, and 5 mm pole width)
6 = 50 µm (only with 2 mm and 5 mm pole width)
8 = 250 µm (only with 10 mm pole width)
Cover strip
0 = without cover strip
3 = with cover strip
Length in cm
0100 = ordering length 100 cm (0007...4800)
Reference point position in cm
R0000 = without reference point or pole-periodic reference point
www.balluff.com
-...
BML - M02 - I 4 5 - A3 - M0100 - R0000
