Controls

GB
IE
Car radio (see front fold out fl ap)
Figure A:
Button
Button
2
3 MD/PTY button: Setting the operating mode / setting the PTY function
Button ▸▸I: Title / Station search forwards
4
Display
5
USB port
6
BD/DISP: Select memory level FM 1–3 / showing display information
7
AUX: 3.5 mm stereo input socket for the connection of an external audio device
8
6/FL+ button: Station memory location 6 / directory forwards during MP3/WMA playback
9
5/FL- button: Station memory location 5 / directory backwards during MP3/WMA playback
10
4/RDM button: Station memory location 4 / random play during MP3/WMA playback
11
3/INT button: Station memory location 3 / intro function during MP3/WMA playback
12
2/RPT button: Station memory location 2 / repeat function during MP3/WMA playback
13
1/PAU button: Station memory location 1 / pause playback (Pause)
14
I◂◂: Title / Station search backwards
15
A/PS
16
Multi-controller: Turn to set values/volume
17
SEL (EQ/LD TA/AF) button: Call up Settings menu
18
Figure B:
Locking the face plate
19
Holder for face plate
20
Card reader for SD/MMC cards
21
RESET: Resetting the device
22
Figure C:
ISO block connection B
23
Automotive blade type fuse 7.5 A
24
ISO block connection A
25
SUBW: Audio cinch output for subwoofer
26
LINE OUT: Audio cinch output L/R for amplifi er
27
Antenna socket for DIN antenna plug
28
6
: Unlocking the face plate
/MU: Switching the device on and off / turning the sound off (MUTE)
: Automatic station memory / search function during MP3/WMA playback
SAR 28 A1
