DGC-8/12
Pneumatic linear drive type
1
Operating parts and connections
4
3
2
1
Compressed air port
1
2
Alternative compressed air port
(at side / at rear)
3
Internal thread for fastening the cylinder
foot or for direct fastening
Shock absorber or elastomer absorber
4
(can be replaced, see "Commissioning")
Fig. 1
Festo DGC-8/12 0212NH English
DGC-8/12English
5
6
7
8
Centering holes
5
6
Fastening holes
7
Guide
Groove for proximity switch
8
