11 Technical Data

11.1

General Data

Display: 6-digit, 14 segment LED
Digit height: 14 mm
Data retention: > 10 years, EEPROM
Operation: 5 keys
11.2

Measuring signal inputs

Sampling rate: 10 readings/sec
Input resistance: 1 MΩ
Max. measuring
approx. ± 35 mV
signal range:
±10 V.
Max. voltage
Strain gauge signal input
Sensitivity: 3.3 mV/V; 3.0 mV/V;
2.0 mV/V
± 15 Bit
Resolution:
Measuring accuracy typ. 0.05 % of range
max. ≤0.1 % of range
@ 23°C:
Temperature drift: < 100 ppm/K
Sensitivity: 1.5 mV/V; 1.0 mV/V
± 14 Bit
Resolution
Measuring accuracy typ. 0.1 % of range
max. ≤0.2 % of range.
@ 23°C:
Temperature drift: < 100 ppm/K
11.3

Control Inputs MPI 1 / MPI 2

SELV circuits, reinforced / double insulation
Quantity: 2, optocouplers
Function: programmable
Switching levels: Low: < 2 V
High: > 4 V (max. 30 V)
Pulse length: >100 ms
11.4

Alarm outputs

Relays: changeover contacts
Prescribed fuse: 5A
Switching voltage: max. 250 V AC / 125 V DC
min. 5 V AC / V DC
Switching current: max. 5 A AC/ A DC
min. 10 mA
Switching capacity: max. 1250 VA / 150 W
Pull-in time: approx. 10 ms
The maximum values shall in no case
be exceeded!
Mechanical service life (switching cycles)
N° of switching cycles at 5 A / 250 V AC
N° of switching cycles at 5 A / 30 V DC
11.5

Supply voltage

AC supply: 100 ... 240 V AC / max. 9 VA
50 / 60 Hz, Tolerance ± 10%
DC supply:
Mains hum
suppression:
11.6

Sensor supply voltage

for AC supply:
for DC-supply:
11.7

Climatic Conditions

Operating temperature: -20°C ... +65°C
Storage temperature:
Relative humidity:
Altitude:
11.8

EMC

Noise immunity:
Noise emission:
11.9

Device Safety

Design to:
Protection Class:
Only the front side is classified as
accessible for the operator.
Application area:
Insulation:
Signal inputs and und sensor power supply: SELV

11.10 Mechanical Data

Housing:
Dimensions:
Panel cut-out:
Installation depth:
Weight:
Protection:
Housing material:
7
1x10
Vibration resistance: 10 - 55 Hz / 1 mm / XYZ
4
5x10
EN 60068-2-6
4
5x10
Shock resistance:
EN 60068-2-27
EN 60068-2-29
ext. fuse protection: T 0.1 A
10 ... 30 V DC / max. 3.8 W
with galvanic isolation and,
reverse polarity protection
SELV, CLASS II (Limited
Power Source)
ext. fuse protection: T 0.4 A
50 Hz or 60 Hz,
programmable
24 VDC ±15 %, 30 mA
10 VDC ±1 %, 30 mA
10 VDC ±1 %, 30 mA
-25°C ... +75°C
R.H. 93 % at +40°C,
non-condensing
up to 2000 m
EN 61000-6-2
with shielded signal and
control cables
EN 55011 Class B
EN 61010 Part 1
Protection Class 2 (front side)
Pollution level 2
over-voltage Category II
Front: double insulation,
Rear side: basic insulation,
Panel mount housing
to DIN 43 700, RAL 7021
96 x 48 x 102 mm
+0.8 +0.6
92 x 45 mm
approx. 92 mm incl. terminals
approx. 180 g
IP65 (front, device only)
Polycarbonate UL94 V-2
30 min in each direction
100G / XYZ
3 times in each direction
10G / 6 ms / XYZ
2000 times in each direction
Page 19
