Wet Conditions Maintenance

• Remove the battery pack(s) and dry the contacts. If you have an air
compressor or a can of compressed air, blow out any water that may be
inside the recessed connector housing.
• Remove the tires/wheels from the vehicle and gently rinse the mud and dirt
off with a garden hose. Avoid rinsing the bearings and transmission.
NOTICE: Never use a pressure washer to clean your vehicle.
• Use an air compressor or a can of compressed air to dry the vehicle and
help remove any water that may have gotten into small crevices or corners.
Transmitter
Frequency
Battery
Servo
Power Supply
Output Torque
Operating Speed
Size
Quick Start....................................................................................................4
Vehicle Preparations ....................................................................................4
Charging the Vehicle Battery ....................................................................4
Charging Warnings ...................................................................................4
Installing the Battery.................................................................................5
Transmitter Controls ..................................................................................5
Installing Transmitter Batteries ................................................................5
Binding ......................................................................................................6
Changing the Throttle Limit ......................................................................6
Getting Started..........................................................................................6
Operation......................................................................................................7
When You Are Finished................................................................................7
Motor Care ...................................................................................................7
Maintenance ................................................................................................8
RUCKUS | TORMENT | K&N TORMENT
®
SPECIFICATIONS
2.4GHz
AA x 4
4.8V~6V
41.66 oz (3 kg-cm)
0.23sec/60 degrees of travel
55.6 x 18 x 30mm
COMPONENTS
TABLE OF CONTENTS
• Spray the bearings, drive train, fasteners and other metal parts with a
water-displacing light oil or lubricant. Do not spray the motor.
• Let the vehicle air dry before you store it. Water (and oil) may continue to
drip for a few hours.
• Increase the frequency of disassembly, inspection and lubrication of the
following:
• Front and rear axle hub assembly bearings.
• All transmission cases, gears and differentials.
• Motor-clean with an aerosol motor cleaner and re-oil the bushings
with lightweight motor oil.
Electronic Speed Control (ESC)
Input Voltage
Electric Capacity
Electric Capacity
PWM Frequency
BEC Voltage
Size
Weight
• ECX ® Ruckus
Truck or K&N Torment
• Spektrum
™
• AA (4) Batteries
• 10W LiPo AC Balance Charger
• Dynamite
®
with EC3
™
• Dynamite
®
• Dynamite
®
2.4GHZ DIGITAL
• Spektrum
™
RADIO SYSTEM
Setting the Gear Mesh..............................................................................8
Electronic Speed Control (ESC) .................................................................8
Electrical Layout ........................................................................................8
Shock Cleaning..........................................................................................9
Fasteners ......................................................................................................9
Troubleshooting Guide ...............................................................................10
Limited Warranty .......................................................................................11
Warranty and Service Contact Information ...............................................12
FCC Information..........................................................................................12
IC Information.............................................................................................12
Ruckus Parts Diagram ......................................................................... 46-47
Torment Parts Diagram ....................................................................... 48-49
Replacement Parts .....................................................................................50
Optional Parts.............................................................................................51
™
2S, 5-7 cells NiMH/NiCd
Forward 40A/180A
Reverse 20A/90A
1kHz
5V/2A
42 x 37 x 20mm
44 g
® Monster Truck or Torment ™ Short Course
Short Course Truck
™
STX2 2-CH Transmitter
™
7.4V 1800mAh 2S 20C LiPo, Hardcase
connector
15T Brushed Motor
40A WP Brushed ESC
SRX200 2-CH Receiver
™
EN
3
