Mechanical design

T20WN
T21WN
T22
Supply
voltage
Fig. 4.2 Connection clamps in the opened VK20A junction box
8
1 6 1 6
St1 St2
St7
6 1
External control signal
A02335_03_Y00_00 HBM: public
1 6 1 6
St3 St4
St8
St6 St5
6 1 6 1
Md [V]
Md [I])
n
VK20A
