KNOW YOUR MACHINE
20 Solution Manifold (Cylindrical Models Only)
21 Idler Assembly (Cylindrical Models Only)
22 Debris Hopper (Cylindrical Models Only)
23 Palm Drive Buttons
24 Reverse Button
25 Solution Control
26 Speed Limit Control Knob
27 Battery Hour Gauge
28 Water proof Key Switch
29 Recovery Tank Drain Hose
38
20
21
22
11/2015
INSTRUCTIONS FOR USE
30 Squeegee Raise / Lower Lever
31 Solution Drain Hose / Level Indicator
32 Scrub Deck Raise / Lower Lever
33 Squeegee Mount Thumb Nut
34 Recovery Hose
35 Squeegee Blade Tension Strap
36 Squeegee Blade Alignment Pins
37 Squeegee Blade Latch
38 Onboard Battery Charger (Not found on all models)
24
23
29
35
36
37
